项目Item |
单位Unit |
规范Values |
测试标准Testing StandardASTM |
密度Density |
kg/m3 |
40 |
D1622 |
导热系数 Thermal Conductivity |
|
0.0231(+40°C) |
C177 |
0.0218(+20°C) |
0.0212(+10°C) |
0.0205 (+0°C) |
0.0199(-10°C) |
0.0193(-20°C) |
0.0186(-30°C) |
0.0173(-50°C) |
0.0142(-100°C) |
0.0130(-120°C) |
0.0105(-160°C) |
抗压强度10%(常温)I’vepressive Strength |
Kpa |
各方向≥220(23°C)
All direction≥220(23°C) |
D1621 |
各方向≥280(-165°C)
All direction≥280(-165°C) |
吸水率Water Absorption |
% |
≤2.5 |
C534 |
水蒸气透湿率Permeability |
G/(m2.h) |
≤0.8 |
E96 |
线性热膨胀系数 Linear Heat Expand Coefficient |
M/(m.k) |
≤70×10-6 (23°C) |
D696 |
氯离子含量Chlorides Content |
ppm |
≤60 |
C871 Procedure 2 |
燃烧性能Ignitability Property |
火焰燃烧速率
Flame Spread Index(FSI) |
|
5 |
E84 |
烟密度发散等级
Smoke Devel Open Index(SDI) |
|
0 |
氧指数
Oxygen Index(IO) |
% |
≥32 |
GB2406 |
垂直燃烧
Vertical Flammability |
|
平均燃烧时间≤20s
Average period≤20s
平均燃烧高度≤150mm
Average height≤150mm |
GB8333 |
烟密度
Smoke Density |
|
≤50 |
GB8627 |
|
ISONOL PIR-40K符合上述GB8624中6.4条规定的B1级要求
ISONOL PIR-40K meet GB8624 6.4 B1 Requirement |
