A / D conversion speed |
200 times / sec |
Connecting the Sensor number |
Then eight 350Ω's Sensor, 16 700Ω Sensor |
Sensor links method |
6-wire, automatic long-term compensation, the compensation range of ≦ 50 meters |
Verification number of divisions |
3000 |
The maximum external number of divisions |
30, 000 |
Maximum within a number of divisions |
600, 000 |
Scale value |
1/2/5/10/20/50/100 optional |
Display |
7 LED Digital tube, seven status indicator, 3 level indicator |
Clock |
Real-time clock, automatic leap year and leap month, lights out |
Large-screen interface |
Have |
Signal output mode |
Serial output |
Signal |
200mA current loop (constant current source) |
Baud rate |
600 |
Print Interface |
Have |
Data output mode 1 |
Can be micro-printer optional panel-type Chinese characters (only D10P) |
Data output |
Configuration standard parallel interface |
Can be connected to the line printer Model |
LQ-300K, KX-P1131, KX-P1121 |
Serial communication interface |
Have |
Standard configuration |
RS232C (optional RS422) |
Baud rate |
600/1200/2400/4800 optional |
Transmission distance |
RS-232C ≦ 30m; RS422 ≦ 1200m (optional) |
AC power |
AC187 ~ 242V; 49 ~ 51Hz |
DC power supply |
DC6V/10Ah |
