Glass lining combined tubular exchanger
Size form
|
Model
|
Heat exchange area
|
D
|
D1
|
A
|
L
|
Orifice
|
Weight
|
|
Type
|
Heat-? m2
|
a
|
b
|
c
|
d
|
e
|
Weight (kg)
|
|
EF-3
|
3
|
426
|
480
|
490
|
2050
|
DN70
|
DN50
|
DN50
|
DN32
|
DN20
|
486
|
|
EF-5
|
5
|
426
|
480
|
490
|
2750
|
DN70
|
DN50
|
DN50
|
DN32
|
DN20
|
626
|
|
EF-8
|
8
|
600
|
680
|
560
|
2750
|
DN80
|
DN70
|
DN70
|
DN40
|
DN20
|
914
|
|
EF-10
|
10
|
600
|
680
|
560
|
3140
|
DN80
|
DN70
|
DN70
|
DN40
|
DN20
|
1126
|
Technical specifications
| Design pressure |
tube pass 0.34
|
jacket 0.34
|
shell pass NP
|
| Design pressure |
tube pass 80
|
jacket 80
|
shell pass 150
|
| Max difference in temp. |
100
|
| heat transfer coefficient
w/m20C |
120-400
|
|
