Max Testing Force (KN) |
100KN |
300KN |
600KN |
1000KN |
2000KN |
testing machine Accuracy Degree |
1 grade /0.5 grade |
Force testing range |
2%-100%FS |
Testing Force precision |
≤display value±1% |
distortion,measuring accuracy |
full range2%-100% range内, better than display value±1% |
Max distance (mm) |
550 |
550 |
550 |
600 |
600 |
Clamp thickness (mm) |
0-15 |
0-15 |
0-30 |
0-40 |
0-50 |
Clamp diameter (mm) |
10-32 |
10-32 |
13-40 |
26-60 |
15-70 |
Compression space distance
(mm) |
0-450 |
0-450 |
0-450 |
0-470 |
0-600 |
Working piston stroke, not less than (mm) |
200 |
200 |
200 |
250 |
280 |
Size of pressing plate
(mm) |
170*170 |
170*170 |
170*170 |
204*204 |
204*204 |
Distance of rollers of tension/compression space |
≥450 |
≥450 |
≥450 |
≥600 |
≥700 |
Size(L×W
× high mm) |
800*700*2000 |
900*850*2050 |
900*850*2150 |
960*1000*2200 |
1250*800*3500 |
Size of oil source (L×W
× high mm) |
600*600*1200 |
600*600*1200 |
600*600*1200 |
1280*600*960 |
1080*600*960 |
Weight of mainframe |
1800kg |
2200kg |
2500kg |
3000kg |
8000kg |
