Application Scope
Vacuum belt dryer(VBD) is fit for drying all kinds of liquid or pasty, soild power material, such as traditional chinese and western medicines, food, biological products, chemical material, health food,food additive, etc.
VBD is especially suitable for drying high-viscosity, easy for mass formation, thermoplastic and thermal sensitive material which can not be dryed by means of spray drying. For these material, VBD is the best choice.
Working principle
The dryer can accomplish continuous feeding and continous discharging of material in vacuum state, transform the conventional static drying to vacuum dynamic, reduce traditional drying time from of 10-20 hours to of 30-60 minutes, reach the goal of adjusting the drying temperature according to different materials, settle the difficulty that spray drying can not solve, remove the problem that traditional drying oven spend a long time and cause the material deformed. The MJ`s dry what other companies made dryers can dry and what other companies made dryers can not dry. The material`s colour and lustre, solubility and physical property after drying can be reserved very well. This feature can not be reached by other companies made dryers.
Equipment advantages
- the whole process flow can be finished automaticly, hermeticly, continously and programmed.
- drying temperature can adjusted within the scope of 20-150°C.
- The drying process is completed in vacuum state.
- Thermal-sensitive material can keep their property unchanged and uncontaminated.
- Operation cost of dryer is only 1/3 of that consumed by traditional drying.
- Moisture content of product after drying can be adjusted.
- The dryer can dry liquid and solid material of high viscosity and high hydration.
- The dryer can continuously put out dry powder 30-60 minutes later after starting drying process, the dry powder recovery rate is 99%.
- The dryer adopts PLC control system including continous operation protective device.
- The dryer owns CIP automatic cleaning system and fulfills GMP guideline.
Type and technical parameters [ the last number of type is drying belt layers ]
Type |
Drying temperature
°C |
Moisture content of Feeding material % |
Moisture content of dry powder % |
Evaporated water quantity
kg/h |
dryer electrical Power
kw |
Matched heat source |
CIP cleaning pressure
MPa |
MJ100-1 |
25-120 |
25-80 |
1-4 |
2-3 |
4.00 |
Steam or hot water or hot oil |
0.3-1.0 |
MJ100-2 |
25-120 |
25-80 |
1-4 |
5-10 |
4.08 |
0.3-1.0 |
MJ100-3 |
25-120 |
25-80 |
1-4 |
10-15 |
5.00 |
0.3-1.0 |
MJ101-3 |
25-120 |
25-80 |
1-4 |
20-30 |
6.00 |
0.3-1.0 |
MJ101-4 |
25-120 |
25-80 |
1-4 |
25-40 |
7.10 |
0.3-1.0 |
MJ101-5 |
25-120 |
25-80 |
1-4 |
30-50 |
12.00 |
0.3-1.0 |
MJ102-4 |
25-120 |
25-80 |
1-4 |
40-60 |
12.00 |
0.3-1.0 |
MJ102-5 |
25-120 |
25-80 |
1-4 |
60-80 |
14.00 |
0.3-1.0 |
MJ103-4 |
25-120 |
25-80 |
1-4 |
70-90 |
14.50 |
0.3-1.0 |
MJ103-5 |
25-120 |
25-80 |
1-4 |
80-100 |
15.50 |
0.3-1.0 |
MJ103-6 |
25-120 |
25-80 |
1-4 |
90-120 |
16.50 |
0.3-1.0 |
MJ103-8 |
25-120 |
25-80 |
1-4 |
140-160 |
18.50 |
0.3-1.0 |
MJ103-10A |
25-120 |
25-80 |
1-4 |
160-200 |
25.50 |
0.3-1.0 |
MJ103-10B |
25-120 |
25-80 |
1-4 |
180-220 |
25.50 |
0.3-1.0 |
|
