Main technical parameters
| Model |
Unit |
1T |
1.6T |
Nominal force |
KN |
10 |
16 |
Maximum working pressure |
Mpa |
5.5 |
5.1 |
Maximum distance from slider to workbench |
mm |
300 |
300 |
Maximum stroke of slider |
Mm |
120 |
160 |
Downstream speed of slider |
Mm/s |
60 |
45 |
Return stroke speed of slider |
Mm/s |
100 |
90 |
Throat depth |
Mm |
110 |
120 |
Table size |
Front and back |
Mm |
250 |
250 |
Left and right |
Mm |
300 |
300 |
Motor power |
KW |
1.1 |
1.1 |
Mechine overall dimension |
Front and back |
Mm |
600 |
600 |
Left and right |
Mm |
500 |
500 |
Height |
Mm |
1600 |
1600 |
Total weight (about) |
kg |
250 |
400 |
|
