| Model |
Unit |
Specification |
Y28-50 |
Y28-120 |
Y28-220 |
Y28-220L |
Y28-275 |
Y28-350 |
Y28-350L |
Y28-500 |
Y28-500L |
Y28-600 |
Main cylinder |
Nominal force |
Ton |
35 |
85 |
160 |
160 |
200 |
260 |
260 |
350 |
350 |
420 |
Maximum stroke |
mm |
350 |
450 |
560 |
560 |
560 |
560 |
560 |
600 |
600 |
700 |
Blank pressing cylinder |
Nominal force |
Ton |
15 |
35 |
60 |
60 |
75 |
90 |
90 |
150 |
150 |
180 |
Maximum stroke |
mm |
175 |
200 |
260 |
260 |
260 |
600 |
260 |
300 |
300 |
350 |
Discharging cylinder |
Nominal force |
Ton |
2 |
3 |
5 |
5 |
5 |
5 |
5 |
10 |
10 |
10 |
Maximum stroke |
mm |
150 |
180 |
200 |
200 |
200 |
220 |
220 |
250 |
250 |
300 |
Open height |
mm |
600 |
730 |
900 |
1000 |
900 |
900 |
900 |
1000 |
1200 |
1500 |
Distance from the fixed workbench to ground |
mm |
990 |
1055 |
1080 |
1100 |
1100 |
1200 |
1200 |
1550 |
1600 |
1700 |
Downstream speed of movable workbench |
mm/s |
195 |
220 |
210 |
210 |
210 |
200 |
200 |
210 |
210 |
190 |
Drawing speed of movable workbench |
mm/s |
25 |
20 |
20 |
20 |
19 |
17 |
17 |
18 |
18 |
14 |
Return stroke speed of evelated of movable workbench |
mm/s |
180 |
220 |
200 |
200 |
200 |
165 |
165 |
190 |
190 |
180 |
Rising velocity of bottom cylinder |
mm/s |
120 |
50 |
120 |
120 |
115 |
160 |
160 |
85 |
85 |
75 |
Effective size of workbench |
Left and right |
mm |
500 |
50O |
710 |
900 |
800 |
900 |
1100 |
1050 |
1250 |
1400 |
Front and back
(edge) |
mm |
550 |
600 |
870 |
1100 |
900 |
1000 |
1250 |
1200 |
1500 |
1600 |
Overall dimension |
Left and right |
mm |
1750 |
1990 |
20900 |
2280 |
2190 |
2200 |
2400 |
2970 |
3090 |
3690 |
Front and back |
mm |
1160 |
1510 |
1500 |
1750 |
1650 |
1850 |
1850 |
2200 |
2400 |
2000 |
Height |
mm |
2550 |
2920 |
3500 |
3500 |
3600 |
3800 |
3840 |
4680 |
4800 |
5640 |
Motor power |
kw |
7.5 |
15 |
30 |
30 |
30 |
37 |
37 |
55 |
55 |
55 |
Weight (reference) |
kg |
2280 |
3500 |
6000 |
6600 |
7500 |
9500 |
12500 |
16000 |
22000 |
23000 |
Four column hydraulic press series
